PLUSE POSITION MODULATION & DEMODULATION TRAINER KIT

Home Electronics Basic Communication Lab PLUSE POSITION MODULATION & DEMODULATION TRAINER KIT
PLUSE POSITION MODULATION & DEMODULATION TRAINER KIT
PLUSE POSITION MODULATION & DEMODULATION TRAINER KIT

PLUSE POSITION MODULATION & DEMODULATION TRAINER KIT

Category: Electronics

Model No:IBC- 104

Pluse Position Modulation and Demodulation Trainer is a useful training product for the students to help them understand the concept of Modulation and Demodulation. Pluse Position Modulation is an effective technique used to transmit the information signal over a long distance without any distortion in it. It is a kind of modulation where the amplitude of the carrier signal is changed in proportion to the message signal while the phase and frequency are kept constant.


    Share:

Product Description

Pluse Position Modulation and Demodulation Trainer is a useful training product for the students to help them understand the concept of Modulation and Demodulation. Pluse Position Modulation is an effective technique used to transmit the information signal over a long distance without any distortion in it. It is a kind of modulation where the amplitude of the carrier signal is changed in proportion to the message signal while the phase and frequency are kept constant.

Features:

  • Glass Epoxy PCB used as front panel
  • Demodulation of PPM using 4th order /low pass filter &  AC amplifier using TL 07 4

Scope of Learning:

  • Observe change in the carrier amplitude according to the amplitude of the modulating signal.
  • Recovery of modulating signal from demodulator circuit

Technical Specifications:

  • Power Supply    :      + 12 V, + 5V / 300mA

Signal Generator

  •     Frequency     :      8K, 16K , 32K , 64K
  •     Amplitude      :       0-5 Vpp Approx.

Carrier Signal Generator

  •  Frequency            :     455 Khz
  •  Amplitude             :     2.5  Vpp
  • Demodulation        :    Diode detector OZ 79
  • Modulation            :    using IC 7555 Multivibrator
  • Mains                    :     230V AC ±10%,50Hz
  • Fuse                     :     500mA
  • Dimension            :     W 215 x D 195 x H130

Required Accessories :

  • Dual Trace DSO/CRO 20MHz
